ARCTIC-T2-MINI-ULTRA 3kW - 12kW
Our mini electric boilers are ideal for heating single- family homes and condominiums. These compact heaters can effortlessly fit into very small spaces. What’s more: the boilers come in a variety of configurations, making them easy to install.
Our mini electric boilers are renowned for their compact design. Thanks to their reduced
sizes, these heating systems fit into even the smallest of spaces. In addition, the piping can be connected in multiple ways, ensuring an effortless installation.
Our boilers waste no energy. Producing no combustion or GHG emissions, the mini electric boiler is a highly energy-efficient and green alternative. Maintenance is simple and kept to a minimum. The addition of the UltraSmart TM controller also helps to increase overall system performance.
Silent and discreet, mini electric boilers are ideal for single-family homes and condominiums. Whether you need a hydronic system to heat your basement, garage or any other type of application, the compact mini is the intelligent choice for heating.
Features & Specs
- The UltraSmart TM controller enables users to view the boiler’s operation status at a glance
- Preset configurations based on heating distribution
- system Outdoor sensor that modulates boiler water temperature
- Heating stops when outside temperature gets warmer
- “Boost” mode that automatically increases the temperature when needed
- Ability to purge the pump when system is not running
- Safety control to limit excessively high temperatures
- 120V pump power supply
- 24V electrical supply for thermostat and other accessories
- 30 PSI safety relief valve
- Drain/purge valve
- 208/240 VAC electrical supply
- Length: 8 3/4" Width: 8 7/8" Height: 21 1/2"
- Weight: 47 lbs
- Volume: 1 US Gallon
- Maximum Operating Pressure: 30 PSI
- 4 Inlet and Outlet Connections 3/4" NPT FEM
MINI ELECTRIC BOILERS ARE IDEAL FOR HEATED FLOORS, RADIATORS AND HOT WATER BASEBOARDS. OUR BOILERS CAN ALSO BE THE PERFECT SOLUTION TO COMPLEMENT YOUR EXISTING GEOTHERMAL, HEAT PUMP, BIOMASS OR SOLAR ENERGY HEATING SYSTEM.
15 Year warranty on reservoir
2 Year warranty on Electrical and Mechanical Parts
