Lawler 86004 Cabinet With 802 High-Low Mixing Valves

Lawler 86004 Cabinet With 802 High-Low Mixing Valves

  • $5,393.00
  • Save $-257


  Most Items Ship Same Day   (Warranty, Return and Refunds)


Lawler's 86004 Cabinet with 802 High-Low Thermostatic Mixing Valve provides tempered water over a wide range of flows in a single valve unit. Ideally suited for institutional and commercial applications such as group showers, schools, hotels, hospitals, prisons, and nursing homes. The 802 will provide from 2 to 80 gpm @ 45 psi (1/2 gpm when properly installed in a recirculated system). This valve provides three-way protection from scalding upon: 1) failure of the thermostat, 2) shut-off of hot water, or 3) shut-off of cold water. This one piece, single body valve contains a liquid filled thermostat, a stainless steel piston and liner, and is ASSE 1017 and CSA B125.3 approved. This single valve is easier to install, easier to maintain and more cost efficient than multi-valve systems on the market.

Specifications:

Series: 800
Valve: 802
Configuration: Standard
Application: Master Controller
Certification/s: ASSE 1017, CSA B125.3, Lead Free
Connection Type: NPT
Inlet Connection Size: 1"
Outlet Connection Size: 1-1/4"
Min Flow: 2 GPM
Min Flow with Recirculation: 1/2 GPM"
Rated Flow at 10 PSI: 39 GPM"
Rated Flow at 45 PSI: 80 GPM"
Temperature Range: 90°F – 120°F
Weight: 99 lbs
Part Number: 86004



Documents and guides:

Read more...
shop pay installments buy now pay later
(Open hours: 9:00 AM - 5:00 PM)

Disclaimer: Must be installed by a licensed contractor or warranty is void.
