Rusco 3/4" Spin-Down Sediment Filter | Polyester or Stainless Mesh
Rusco 3/4" Spin-Down Sediment Filter | Polyester or Stainless Mesh - Polyester / 700 Microns 24 Mesh is backordered and will ship as soon as it is back in stock.
Rusco 3/4" Spin-Down Sediment Filter
The Rusco 3/4" Spin-Down Sediment Filter provides reusable sediment filtration for applications such as well water, irrigation, and sediment pre-filtration. The spin-down design allows accumulated sediment to be flushed from the housing while the reusable screen can be removed and cleaned when required.
This family uses 3/4" female pipe thread connections, supports a flow range of 1–25 GPM, and has a maximum working pressure rating of 150 PSI.
Polyester mesh options provide a broad range of sediment filtration levels. Rusco also offers stainless-steel screen configurations for applications requiring increased durability or resistance to abrasive sediment.
Rusco 3/4" Spin-Down Key Features
| Feature | Rusco Verified Data |
|---|---|
| Product Type | Spin-Down Sediment Filter |
| Connection Size | 3/4" |
| Connection Type | Female Pipe Thread (FPT) |
| Flow Range | 1–25 GPM |
| Maximum Working Pressure | 150 PSI |
| Product Dimensions | 11-3/8" L × 5" W |
| Filter Media | Polyester Mesh |
| Screen Type | Washable / Reusable |
| Available Mesh | 24–1000 |
| Micron Range | 700–15 Micron |
| Typical Applications | Well Water, Irrigation, Sediment Pre-Filtration |
Rusco 3/4" Spin-Down Technical Specifications
| Specification | Value |
|---|---|
| Manufacturer | Rusco |
| Series | Spin-Down |
| Product Type | Sediment Filter |
| Connection Size | 3/4" |
| Connection Type | FPT |
| Flow Range | 1–25 GPM |
| Maximum Pressure | 150 PSI |
| Product Dimensions | 11-3/8" L × 5" W |
| Filter Material | Polyester Mesh |
| Screen Service | Reusable / Washable |
| Mesh Options | 24, 30, 40, 60, 100, 140, 250, 500, 1000 |
| Micron Range | 700–15 Micron |
Rusco Spin-Down Mesh Options
| Mesh | Media | Service |
|---|---|---|
| 24 | Polyester Mesh | Washable / Reusable |
| 30 | Polyester Mesh | Washable / Reusable |
| 40 | Polyester Mesh | Washable / Reusable |
| 60 | Polyester Mesh | Washable / Reusable |
| 100 | Polyester Mesh | Washable / Reusable |
| 140 | Polyester Mesh | Washable / Reusable |
| 250 | Polyester Mesh | Washable / Reusable |
| 500 | Polyester Mesh | Washable / Reusable |
| 1000 | Polyester Mesh | Washable / Reusable |
Applications
- Well-water sediment filtration
- Irrigation systems
- Pre-filtration ahead of finer filtration equipment
- Removal of sand and other suspended sediment
- Applications requiring a reusable flushable screen
