Senville AURA Concealed Duct Mini Split Heat Pumps | 9K–24K
Senville AURA Concealed Duct Mini Split Heat Pumps | 9K–24K - 9000 / No Line Set is backordered and will ship as soon as it is back in stock.
The Senville AURA Concealed Duct Mini Split Heat Pump family provides discreet, high-efficiency heating and cooling for residential and light commercial spaces. The indoor air handler is designed to be installed above a ceiling or within a concealed space and connected to short duct runs, giving you the comfort of a ducted system without a visible wall-mounted unit.
The family is available in 9,000, 12,000, 18,000, and 24,000 BTU sizes. All four current models use R-454B refrigerant, operate on 208/230V single-phase power, and are designed for cold-climate operation down to approximately -22°F / -30°C. Senville also lists these concealed-duct systems as ENERGY STAR certified, with professional installation required.
Each capacity is offered with your choice of no line set, 16-ft, 25-ft, or 50-ft installation-kit configuration.
⚙️Key Features:
| Feature | Specification |
|---|---|
| Manufacturer | Senville |
| Series | AURA |
| Product Type | Concealed Duct Mini Split Heat Pump |
| Available Capacities | 9K / 12K / 18K / 24K |
| Heating & Cooling | Yes |
| Indoor Unit Style | Concealed Duct |
| Power Supply | 208/230V, 1Ph, 60Hz |
| Refrigerant | R-454B |
| Cold-Climate Heating | Down to -22°F / -30°C |
| Installation Options | NL / 16 ft / 25 ft / 50 ft |
| Warranty | 10-Year Compressor / 5-Year Parts |
| Installation | Professional installation required |
📊 Technical Specifications Table
| Specification | 9K | 12K | 18K | 24K |
|---|---|---|---|---|
| Model | SENA-09HF-ID | SENA-12HF-ID | SENA-18HF-ID | SENA-24HF-ID |
| SEER2 | 21.4 | 20 | 18 | 19 |
| EER2 | 13.4 | 12 | 12 | 12 |
| Cooling Capacity | 9,000 BTU | 12,000 BTU | 17,000 BTU | 24,000 BTU |
| Heating Capacity | 10,000 BTU | 12,500 BTU | 19,000 BTU | 26,000 BTU |
| Power Supply | 208/230V 1Ph | 208/230V 1Ph | 208/230V 1Ph | 208/230V 1Ph |
| Refrigerant | R-454B | R-454B | R-454B | R-454B |
| Heating Minimum | -22°F | -22°F | -22°F | -22°F |
| Pre-Charge | 25 ft | 25 ft | 25 ft | 25 ft |
| Control Type | Wired Control | Wired Control | Wired Control | Wired Control |
| Warranty | 10/5 | 10/5 | 10/5 | 10/5 |
⚙️Technical Documents:
