SANCO2 80 Gallon + 13.5kw ECO-80SW13

ECO-80SW13 – 80 Gallon & 13.5kW Swing Tank

The ECO-80SW13 Swing Tank is a high-performance, 80-gallon storage solution designed for use with GS5-45HPC & -D heat pumps. Built with durable construction, advanced insulation, and reliable heating elements, it ensures efficient hot water delivery for commercial and residential applications.

🔧 Construction & Durability

• Heavy-duty mild steel tank with a baked-on cobalt-enriched porcelain glass lining for long-lasting protection.

• Exterior finished with a baked-on powder-coated steel jacket.

• Certified Indoor Only installation (not for outdoor use).

• Supplied with 2 x Magnesium Anodes for superior corrosion resistance.

🔥 Performance & Capacity

• Tank Volume (Actual/Nominal): 80 Gallons

• Capacity per Heat Pump: 4.5kW or 15,400 Btu/h

• Recovery per HP @ 90°F Rise: 20.6 GPH (Gallons per Hour)

• Installed Tank Weight: 350 lbs | Shipping Weight: 395 lbs

💧 Connections

• Recirculation/Heat Pump Manifold Inlet: 1 ½” NPT

• Hot Water Outlet: 1 ½” NPT

⚡ Electric Heating Elements

• 1 Low Watt Density Incoloy Element (resists corrosion, acids, high temps, and thermal shock).

• Output: 13.5 kW

• Number of Element Contactors: 2

• Voltage & Breaker Sizes:

  • 208V-1Ph: 64.9A / 90A

  • 240V-1Ph: 56.2A / 80A

  • 208V-3Ph: 37.5A / 50A

  • 240V-3Ph: 32.5A / 45A

🌡 Controls & Safety

• Digital Control System with adjustable immersion thermostat.

• Factory preset to 120°F (49°C).

• Cartridge fuses rated at 200,000 AIC.

• Supplied with ASME-approved Pressure Relief Valve (150 Psig setting).

• Electric panel is indoor rated only (not waterproof).

🛡 Insulation & Efficiency

• 3” high-density closed-cell foam insulation reduces heat loss.

• Meets ASHRAE 90.1b energy standard (max 4 watts per sq. ft. energy loss).

✅ Certifications & Warranty

• UL & ULC listed tank.

• 5-Year Tank Warranty.

Technical Documents:

• Submittal
