SANCO2 80 Gallon + 13.5kw ECO-80SW13
SANCO2 80 Gallon + 13.5kw ECO-80SW13 is backordered and will ship as soon as it is back in stock.
ECO-80SW13 – 80 Gallon & 13.5 kW Swing Tank
The ECO-80SW13 Swing Tank is a high-performance, 80-gallon storage solution designed for use with GS5-45HPC and GS5-45HPC-D heat pumps. Durable construction, advanced insulation, and a 13.5 kW electric heating element support hot water storage and supplemental heating for commercial and residential applications.
Construction & Durability
| Feature | Construction Details |
|---|---|
| Tank Material | Heavy-duty mild steel. |
| Interior Lining | Baked-on cobalt-enriched porcelain glass lining for long-lasting protection. |
| Exterior Jacket | Baked-on powder-coated steel jacket. |
| Installation Location | Indoor installation only. Not for outdoor use. |
| Anode Protection | 2 magnesium anodes for corrosion resistance. |
Performance & Capacity
| Specification | Details |
|---|---|
| Model | ECO-80SW13 |
| Tank Volume — Actual/Nominal | 80 gallons |
| Compatible Heat Pumps | GS5-45HPC and GS5-45HPC-D |
| Capacity per Heat Pump | 4.5 kW or 15,400 Btu/h |
| Recovery per Heat Pump at 90°F Rise | 20.6 GPH (gallons per hour) |
| Installed Tank Weight | 350 lb |
| Shipping Weight | 395 lb |
Performance note: Heat pump capacity and recovery figures apply to each connected heat pump, not the tank’s 13.5 kW electric heating element.
Water Connections
| Connection | Size |
|---|---|
| Recirculation / Heat Pump Manifold Inlet | 1½-inch NPT |
| Hot Water Outlet | 1½-inch NPT |
Electric Heating Element
One low watt density Incoloy element resists corrosion, acids, high temperatures, and thermal shock.
| Element Specification | Details |
|---|---|
| Number of Elements | 1 |
| Element Material | Low watt density Incoloy |
| Element Output | 13.5 kW |
| Number of Element Contactors | 2 |
Voltage, Amperage & Breaker Sizes
| Voltage | Phase | Amperage | Breaker |
|---|---|---|---|
| 208 V | Single-phase | 64.9 A | 90 A |
| 240 V | Single-phase | 56.2 A | 80 A |
| 208 V | Three-phase | 37.5 A | 50 A |
| 240 V | Three-phase | 32.5 A | 45 A |
Controls & Safety
| Control / Safety Feature | Details |
|---|---|
| Temperature Control | Digital control system with adjustable immersion thermostat. |
| Factory Temperature Setting | 120°F (49°C) |
| Cartridge Fuses | Rated at 200,000 AIC. |
| Pressure Relief Valve | Supplied with an ASME-approved pressure relief valve; setting 150 psig. |
| Electric Panel | Indoor rated only. Not waterproof. |
Insulation & Efficiency
| Feature | Details |
|---|---|
| Insulation | 3-inch high-density closed-cell foam insulation reduces heat loss. |
| Efficiency Standard | ASHRAE 90.1b |
| Maximum Tank Surface Energy Loss | 4 watts per square foot |
Certifications & Warranty
| Certification / Coverage | Details |
|---|---|
| Tank Listing | UL & ULC |
| Tank Warranty | 5 years |
Technical Documents
