Lawler 86820-01 570 3/8" Standard Under the Counter Valves

Lawler 86820-01 Model 570® Under-the-Counter Mixing Valve
The Lawler 86820-01 Model 570® is a technologically advanced under-the-counter mixing valve designed to deliver safe, tempered water directly at the point-of-use. Compact, easy to install, and economically priced, the Model 570® ensures reliable protection against both scalding and chilling while providing flexible temperature control.
🔑 Key Features & Benefits
-
Advanced Safety Protection – Provides tempered water at the point-of-use, preventing scalding and chilling.
-
Adjustable Temperature Range – Full cold to 115°F, allowing for customized comfort and safety.
-
Tamper-Resistant Design – Engineered to resist unauthorized adjustments for added reliability.
-
Flexible Installation – Can be installed with or without cabinet enclosures for maximum versatility.
-
Cost-Effective Solution – Economically priced without sacrificing quality or performance.
📦 Order the Lawler 86820-01 Model 570® Today
Upgrade your system with the Lawler Model 570® under-the-counter mixing valve—a safe, reliable, and affordable solution for point-of-use water control. Fast, free shipping available.
Specifications:
Series: 570 |
Model: 570-38 |
Configuration: Standard |
Application: Point of Use |
Certification/s: ASSE 1070, NSF 372, NSF 61 |
Connection Type: Compression |
Inlet Connection Size: 3/8" |
Outlet Connection Size: 3/8" |
Min Flow: 1 GPM |
Min Flow with Recirculation: 1/2 GPM" |
Rated Flow at 10 PSI: 1-3/4 GPM" |
Rated Flow at 45 PSI: 3-1/2 GPM" |
Temperature Range: 80°F – 120°F |
Weight: 2 lbs |
Part Number: 86820-01 |
