Rusco 2" L-Style Sediment Trapper Filters - Top-In Side-Out Filtration Systems
Rusco 2" L-Style Sediment Trapper Filters - Top-In Side-Out Filtration Systems - Poyester / 24 Mesh (700 Micron) is backordered and will ship as soon as it is back in stock.
Rusco 2" L-Style Sediment Trapper Filter
The Rusco 2" L-Style Sediment Trapper combines reusable sediment filtration with Rusco's specialized L-Style plumbing configuration.
Unlike the straight-through T-Style body, the L-Style configuration places the water inlet on the side and the outlet on the top. Rusco identifies this configuration for use in jet-pump applications.
The Sediment Trapper design provides additional space below the filtration element where captured sediment can collect before it is discharged through the bottom flush valve. This helps reduce sediment loading directly against the filtration media.
The 2" L-Style Sediment Trapper uses 2" slip connections, measures approximately 18" L × 5-1/2" W, and supports approximately 35–90 GPM.
Available configurations include polyester mesh, stainless steel mesh, and Chemical-Resistant stainless steel models.
Key Features
| Feature | Verified Data |
|---|---|
| Manufacturer | Rusco |
| Product Family | Sediment Trapper |
| Body Style | L-Style |
| Flow Configuration | Side Inlet / Top Outlet |
| Connection Size | 2" |
| Connection Type | Slip |
| Flow Range | 35–90 GPM |
| Product Dimensions | 18" L × 5-1/2" W |
| Standard Media Options | Polyester / Stainless Steel |
| Chemical-Resistant Option | Available with Stainless Steel Mesh |
| Reusable Element | Yes |
| Flush Valve | Included |
Standard Polyester L-Style Sediment Trapper SKUs
| Rusco SKU | Mesh | Approx. Micron |
|---|---|---|
| L 2-24 ST-F | 24 | 711 µm |
| L 2-30 ST-F | 30 | 533 µm |
| L 2-40 ST-F | 40 | 381 µm |
| L 2-60 ST-F | 60 | 254 µm |
| L 2-100 ST-F | 100 | 152 µm |
| L 2-140 ST-F | 140 | 104 µm |
| L 2-250 ST-F | 250 | 61 µm |
| L 2-500 ST-F | 500 | 30 µm |
| L 2-1000 ST-F | 1000 | 15 µm |
Standard Stainless Steel L-Style Sediment Trapper SKUs
| Rusco SKU | Mesh | Approx. Micron |
|---|---|---|
| L 2-30STSS-F | 30 | 533 µm |
| L 2-60STSS-F | 60 | 254 µm |
| L 2-100STSS-F | 100 | 152 µm |
| L 2-140STSS-F | 140 | 104 µm |
| L 2-200STSS-F | 200 | 74 µm |
| L 2-250STSS-F | 250 | 61 µm |
| L 2-500STSS-F | 500 | 30 µm |
| L 2-1000STSS-F | 1000 | 15 µm |
Chemical-Resistant Stainless Steel L-Style SKUs
| Rusco SKU | Mesh | Approx. Micron |
|---|---|---|
| L2-30STSS-CR-F | 30 | 533 µm |
| L2-60STSS-CR-F | 60 | 254 µm |
| L2-100STSS-CR-F | 100 | 152 µm |
| L2-140STSS-CR-F | 140 | 104 µm |
| L2-200STSS-CR-F | 200 | 74 µm |
| L2-250STSS-CR-F | 250 | 61 µm |
| L2-500STSS-CR-F | 500 | 30 µm |
| L2-1000STSS-CR-F | 1000 | 15 µm |
Product Highlights
- Side-inlet / top-outlet L-Style configuration
- Designed by Rusco for jet-pump applications
- Extended Sediment Trapper collection design
- 2" slip connections
- 35–90 GPM flow range
- Reusable polyester and stainless steel elements
- Chemical-Resistant stainless steel versions available
- Bottom flush valve for routine sediment removal
