SANCO2 119 Gallon + 13.5kw ECO-119SW13

ECO-119SW13 – 119 Gallon & 13.5kW Swing Tank

The ECO-119SW13 Swing Tank is a large-capacity, high-efficiency storage tank engineered for pairing with GS5-45HPC & -D heat pumps. With a 119-gallon volume, durable steel construction, and a powerful 13.5kW electric element, this tank ensures dependable hot water supply for demanding commercial or residential applications.

🔧 Construction & Durability

• Heavy-duty mild steel tank with baked-on cobalt-enriched porcelain glass lining.

• Exterior jacket finished with baked-on powder coating for long-term protection.

• Indoor installation only (not certified for outdoor use).

• Equipped with 3 x Magnesium Anodes for superior corrosion resistance.

🔥 Performance & Capacity

• Tank Volume (Actual/Nominal): 119 Gallons

• Capacity per Heat Pump: 4.5kW or 15,400 Btu/h

• Recovery per HP @ 90°F Rise: 20.6 GPH (Gallons per Hour)

• Installed Tank Weight: 550 lbs | Shipping Weight: 742 lbs

💧 Connections

• Recirculation/Heat Pump Manifold Inlet: 1 ½” NPT

• Hot Water Outlet: 1 ½” NPT

⚡ Electric Heating Elements

• 1 Low Watt Density Incoloy Element – resistant to corrosion, scaling, and thermal shock.

• Output: 13.5 kW

• Number of Element Contactors: 2

• Voltage & Breaker Sizes:

  • 208V-1Ph: 64.9A / 90A

  • 240V-1Ph: 56.2A / 80A

  • 208V-3Ph: 37.5A / 50A

  • 240V-3Ph: 32.5A / 45A

🌡 Controls & Safety

• Digital Control System with adjustable immersion thermostat.

• Factory preset to 120°F (49°C).

• Cartridge fuses rated at 200,000 AIC.

• Supplied with ASME-approved Pressure Relief Valve (150 Psig setting).

• Electric panel rated for indoor use only (not waterproof).

🛡 Insulation & Efficiency

• 3” high-density closed-cell foam insulation for reduced standby heat loss.

• Meets ASHRAE 90.1b energy efficiency standard (max 4 watts/sq. ft. energy loss).

✅ Certifications & Warranty

• UL & ULC listed tank.

• 5-Year Tank Warranty.

Technical Documents:

• Submittal
