Schulz Heavy Duty SRS 240 Non- Cycling Refrigerated Air Dryers 972.0372-0

Key features:
- Dew point of 3°C in the most critical conditions of application
- Precooling of air that increases compressor efficiency and reduces energy consumption
- Measure to operate with the smallest pressure drop
- The project is tropicalized, and the dryers are prepared for high temperature variations

Specifications:
- Flow (CFM): 240
- Maximum Pressure (PSI): 218
- Connection (in): 2" BSP
- Voltage (V): 220
- Refrigerant Fluid: R404A
- Frequency (Hz): 60
- Phase: Single
- Dimensions (L X H X W): 33.5” X 63.5” X 29.65”
- Shipping Weight: 300 lbs

Pre Filter-1 micron, Model: 007 0254-0 NPT: 1-1/2"

After Filter-01- micron, Model: 007 0255-0 NPT: 1-1/ 2"

Performance Specifications:

Documents and guides:

• Technical Documents
