Senville ELITE Replacement Outdoor Units | 9K–24K BTU
Senville ELITE Replacement Outdoor Units | 9K–24K BTU - 9000 BTU is backordered and will ship as soon as it is back in stock.
The Senville ELITE Series Replacement Outdoor Unit is designed for replacing the outdoor condenser in a compatible Senville ELITE mini split system. Available in 9,000, 12,000, 18,000, and 24,000 BTU sizes, each outdoor unit should be paired with its corresponding same-capacity ELITE indoor unit.
ELITE outdoor units use variable-speed DC inverter technology and R-454B refrigerant, with cold-climate operation designed for heating in outdoor temperatures down to -22°F (-30°C) when installed as part of the appropriate matched system. Senville also uses an all-weather galvanized steel enclosure for the replacement condensers.
Important: This product is a replacement outdoor unit only and is not a complete mini split system. Confirm the matching Senville ELITE indoor unit before ordering.
⚙️ Key Features
| Feature | Value |
|---|---|
| Manufacturer | Senville |
| Series | ELITE Series |
| Product Type | Replacement Outdoor Condenser Unit |
| Available Capacities | 9,000 / 12,000 / 18,000 / 24,000 BTU |
| Compressor | Variable-Speed DC Inverter |
| Refrigerant | R-454B |
| Cold-Climate Operation | Down to -22°F / -30°C as part of the matched ELITE system |
| Enclosure | All-Weather Galvanized Steel |
| Application | Replacement condenser for compatible Senville ELITE mini split systems |
| Matching Requirement | Corresponding same-capacity ELITE indoor unit |
⚙️Technical Specifications
| Specification | 9,000 BTU | 12,000 BTU | 18,000 BTU | 24,000 BTU |
|---|---|---|---|---|
| SKU | SENE-09EL-OH | SENE-12EL-OH | SENE-18EL-OH | SENE-24EL-OH |
| Product Type | Outdoor Condenser | Outdoor Condenser | Outdoor Condenser | Outdoor Condenser |
| Nominal Family Capacity | 9,000 BTU | 12,000 BTU | 18,000 BTU | 24,000 BTU |
| Power Supply | 208/230V, 1Ph, 60Hz | 208/230V, 1Ph, 60Hz | 208/230V, 1Ph, 60Hz | 208/230V, 1Ph, 60Hz |
| Refrigerant | R-454B | R-454B | R-454B | R-454B |
| Outdoor Airflow – Max | 1,470.6 CFM | 1,470.6 CFM | 2,235 CFM | 2,235 CFM |
| Outdoor Noise Level | 57 dB | 57 dB | 57 dB | 62 dB |
| Minimum Outdoor Heating Temp. | -22°F / -30°C | -22°F / -30°C | -22°F / -30°C | -22°F / -30°C |
| Product Dimensions (W × D × H) | 35.04 × 13.46 × 26.50 in | 35.04 × 13.46 × 26.50 in | 37.24 × 16.14 × 31.89 in | 37.24 × 16.14 × 31.89 in |
| Product Weight | 99.65 lb | 99.65 lb | 130.29 lb | 130.29 lb |
| Matching Indoor Unit | SENE-09EL-IHH | SENE-12EL-IHH | SENE-18EL-IHH | SENE-24EL-IHH |
Matching Indoor Units sold separatly.
| Capacity | Outdoor Replacement SKU | Matching Indoor SKU |
|---|---|---|
| 9,000 BTU | SENE-09EL-OH | SENE-09EL-IHH |
| 12,000 BTU | SENE-12EL-OH | SENE-12EL-IHH |
| 18,000 BTU | SENE-18EL-OH | SENE-18EL-IHH |
| 24,000 BTU | SENE-24EL-OH | SENE-24EL-IHH |
⚙️Technical Documents:
Senville ELITE Replacement Outdoor Units | 9K–24K BTU
