SunEarth SolarStation 1-Line | Commercial Solar Pump Station
SunEarth SolarStation 1-Line | Commercial Solar Pump Station - 1000 SqFt is backordered and will ship as soon as it is back in stock.
SunEarth SolarStation 1-Line Commercial Solar Pump Station
Factory-Assembled Solar Pump Station • Multi-Speed Circulation • Commercial Solar Thermal Applications
The SunEarth SolarStation 1-Line is a factory-assembled commercial solar thermal pump station engineered for small and medium-sized commercial water-heating applications. The SolarStation 1-Line family supports collector installations up to 800 square feet, depending on system design and pump selection.
Designed to simplify field installation, the SolarStation 1-Line provides a preassembled hydraulic pumping solution using commercial-grade components and multi-speed circulator technology. The station is factory tested for hydraulic integrity to support efficient commissioning and dependable operation.
The SolarStation 1-Line is designed for solar thermal applications requiring controlled fluid circulation. Its integrated differential temperature control functionality allows pumps to operate based on system temperature conditions.
The station can also be integrated with compatible SunEarth solar storage tank manifold systems, making it a practical choice for commercial installations requiring increased solar water storage.
Available Pump Configurations
| Manufacturer SKU | Pump Model | Series |
|---|---|---|
| 100005-8-UPS15-58 | UPS15-58 | SolarStation 1-Line |
| 100005-8-UPS26-99 | UPS26-99 | SolarStation 1-Line |
| 100005-8-UPS26-150 | UPS26-150 | SolarStation 1-Line |
Pump and system selection must be based on required flow rate, total dynamic head, collector field arrangement, and the manufacturer-approved design.
Key Features & Benefits
| Feature | Benefit |
|---|---|
| Commercial Solar Thermal Design | Suitable for engineered small- and medium-sized commercial applications. |
| Factory-Assembled Unit | Reduces on-site mechanical assembly and installation requirements. |
| Multi-Speed Circulator | Offers adjustable circulation performance to meet system needs. |
| Differential Temperature Controller | Controls circulation based on solar thermal system temperatures. |
| LCD System Interface | Provides convenient access to operating information. |
| Hydraulic Integrity Testing | Factory testing helps support reliable installation. |
| Storage Manifold Compatibility | Designed to interface with compatible SunEarth storage tank manifold configurations. |
| Multiple Pump Options | Three pump configurations support different hydraulic requirements. |
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | SunEarth |
| Product Series | SolarStation 1-Line |
| Product Type | Commercial Solar Thermal Pump Station |
| Collector Capacity | Up to 800 ft², system dependent |
| Pump Type | Multi-Speed Circulator |
| Pump Configurations | UPS15-58, UPS26-99, UPS26-150 |
| Control Method | Differential Temperature Control |
| Controller Display | LCD |
| Tank System Compatibility | Compatible SunEarth Solar Storage Manifolds |
| Factory Assembly | Yes |
| Hydraulic Testing | Factory Tested |
Product Highlights
- Factory-assembled commercial solar pump station.
- Suitable for solar collector systems up to 800 ft², subject to hydraulic design.
- Three available pump configurations.
- Multi-speed circulation for flexible installation.
- Differential temperature control with LCD interface.
- Factory-tested hydraulic assembly.
- Integrates with compatible SunEarth solar storage tank manifold systems.
- Built for engineered commercial solar water-heating applications.
Technical Documents
- SunEarth 2026 Product Catalog (PDF)
-
SolarStation 1-Line Specification Sheet
- SolarStation Warranty Statement
Engineering & Availability: Product selection requires verification of flow rate, total dynamic head, pump configuration, collector area, and electrical requirements. Confirm current model availability and technical compatibility with SunEarth before ordering.
