SunEarth Standard 3x8 HP Painted Absorber
SunEarth Standard 3x8 HP Painted Absorber is backordered and will ship as soon as it is back in stock.
SunEarth SunBurst PS-24 Standard Plate Absorber
Part Number: PS-24 | Nominal 3 × 8 ft
The SunEarth PS-24 is an all-copper replacement absorber for compatible glazed solar thermal collectors. A painted copper plate transfers collected heat into copper risers and headers.
Confirm enclosure dimensions, connections, and system compatibility before ordering. This item is an absorber assembly; it is not a complete glazed collector.
Product Highlights
- Copper construction: Plate, risers, and headers.
- Painted absorber: Semi-selective finish.
- Replacement component: For compatible collector repairs.
Technical Specifications
| Specification | Details |
|---|---|
| Part Number | PS-24 |
| Nominal Size | 3 × 8 ft |
| Header Size | Verify with Manufacturer |
| Absorber Plate | Roll-formed copper, 0.008 in thick |
| Riser Tubing | Type-M copper; minimum 1/2 in O.D. |
| Gross Area | 24.61 ft² |
| Dry Weight | 20 lb |
| Fluid Capacity | 0.78 US gal |
| Water Design Flow | 0.62 GPM |
| Pressure Drop at Design Flow | 0.017 psig |
| Maximum Flow | 12 GPM |
| Maximum Operating Pressure | 160 psig |
| Header Width | 39-3/8 in |
| Header Center-to-Center Distance | 93-5/8 in |
| Maximum Operating Temperature | Verify with Manufacturer |
Installation
Have a qualified installer confirm fit, fluid compatibility, freeze protection, and operating conditions. Nominal size is not the exact installation envelope.
Warranty
SunEarth’s 10-year limited warranty includes SunBurst absorber plates used in glazed applications, subject to its terms and exclusions. Pool or spa applications require isolation through a heat exchanger for warranty coverage.
Technical Documents
SunEarth Standard 3x8 HP Painted Absorber
