SunEarth Standard 4x10 Standard Plate 1 1/2 HDR Absorber
SunEarth Standard 4x10 Standard Plate 1 1/2 HDR Absorber is backordered and will ship as soon as it is back in stock.
SunEarth SunBurst PS-40-1.5 Standard Plate Absorber
Part Number: PS-40-1.5 | Nominal 4 × 10 ft | 1-1/2-in Header
The SunEarth PS-40-1.5 is an all-copper replacement absorber for compatible glazed solar thermal collectors. A painted copper plate transfers collected heat into copper risers and headers.
Confirm enclosure dimensions, connections, and system compatibility before ordering. This item is an absorber assembly; it is not a complete glazed collector.
Product Highlights
- Copper construction: Plate, risers, and headers.
- Painted absorber: Semi-selective finish.
- Replacement component: For compatible collector repairs.
Technical Specifications
| Specification | Details |
|---|---|
| Part Number | PS-40-1.5 |
| Nominal Size | 4 × 10 ft |
| Header Size | 1-1/2 in nominal copper (1-5/8 in O.D.) |
| Absorber Plate | Roll-formed copper, 0.008 in thick |
| Riser Tubing | Type-M copper; minimum 1/2 in O.D. |
| Gross Area | 40.81 ft² |
| Dry Weight | 36 lb |
| Fluid Capacity | 1.61 US gal |
| Water Design Flow | 1.04 GPM |
| Pressure Drop at Design Flow | 0.020 psig |
| Maximum Flow | 12 GPM |
| Maximum Operating Pressure | 160 psig |
| Header Width | 51-3/8 in |
| Header Center-to-Center Distance | 115-5/8 in |
| Maximum Operating Temperature | Verify with Manufacturer |
Installation
Have a qualified installer confirm fit, fluid compatibility, freeze protection, and operating conditions. Nominal size is not the exact installation envelope.
Warranty
SunEarth’s 10-year limited warranty includes SunBurst absorber plates used in glazed applications, subject to its terms and exclusions. Pool or spa applications require isolation through a heat exchanger for warranty coverage.
Technical Documents
SunEarth Standard 4x10 Standard Plate 1 1/2 HDR Absorber
