SunEarth Standard Absorber Alum 95/20 32SQFT Flat
SunEarth Standard Absorber Alum 95/20 32SQFT Flat is backordered and will ship as soon as it is back in stock.
SunEarth 100011-2-32.1 Aluminum Solar Absorber
Part Number: 100011-2-32.1 | Nominal 32 ft² | Flat Absorber
The SunEarth 100011-2-32.1 is an aluminum solar absorber with copper fluid passages for compatible solar thermal collectors. It is a replacement component, supplied without a complete collector enclosure or glazing.
Match the absorber dimensions, connections, and coating requirements to the existing collector before ordering.
Product Highlights
- Aluminum absorber plate: Transfers collected solar heat to the fluid passages.
- Copper tubing: Carries the system fluid through the absorber.
- Replacement component: For compatible collector assemblies.
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | SunEarth |
| Part Number | 100011-2-32.1 |
| Product Type | Flat solar thermal absorber |
| Nominal Area | 32 ft² |
| Absorber Plate / Fluid Passages | Aluminum / copper |
| Coating and Optical Properties | 90/20 designation per official price list; exact optical tolerances: Verify with Manufacturer |
| Maximum Operating Pressure and Temperature | 160 psig / 400°F — published laser-welded aluminum absorber family design limits |
Installation
Have a qualified installer verify collector compatibility, fit, fluid requirements, freeze protection, and operating limits. Specifications for a complete collector are not automatically the specifications of a replacement absorber.
Warranty
Warranty coverage for this aluminum replacement absorber: Verify with Manufacturer.
Technical Documents
SunEarth Standard Absorber Alum 95/20 32SQFT Flat
