SunEarth THERMORAY Blue TRB-20
SunEarth THERMORAY Blue TRB-20 is backordered and will ship as soon as it is back in stock.
SunEarth ThermoRay Blue TRB-20 Flat-Plate Solar Collector
Part Number: 100009-2-20.1 | 20.6 ft² Gross Area
The SunEarth ThermoRay Blue TRB-20 captures solar energy for water heating with a selective blue absorber surface and copper fluid passages. Its glazed flat-plate construction combines an aluminum absorber with low-iron tempered glass.
A bronze-anodized aluminum frame and insulated backing support outdoor service. The TRB-20 can be incorporated into a professionally designed residential or commercial solar thermal system.
Product Highlights
- Selective blue absorber: Captures sunlight while limiting radiant heat loss.
- Copper fluid passages: Transfer collected heat into the circulating system fluid.
- Tempered glass glazing: Covers the absorber with a durable transparent surface.
- Insulated construction: Helps retain collected heat.
- Integral mounting channel: Accommodates compatible collector mounting hardware.
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer / Model | SunEarth / ThermoRay Blue TRB-20 |
| Part Number | 100009-2-20.1 |
| Collector Type | Glazed liquid flat-plate |
| Length × Width | 61.9 × 48.2 in |
| Gross Area | 20.6 ft² |
| Dry Weight | 62 lb |
| Fluid Capacity | 0.7 gal |
| Absorber | Aluminum; highly selective blue coating |
| Absorptivity / Emissivity | 95% / 5% |
| Headers / Risers | Copper; 1 in nominal / 3/8 in nominal |
| Glazing | Low-iron tempered glass |
| Frame | AA 6063-T6 bronze-anodized aluminum |
| Insulation | Polyisocyanurate and fiberglass; R ≥ 12 |
| Maximum Operating Pressure | 160 psi |
| Maximum Wind / Snow Load | ±90 psf |
| Design Flow Rate | 0.51 gpm |
| Maximum Flow Rate | 12 gpm |
| Standard Connection | 1 in nominal copper sweat |
Cold-weather systems require appropriate freeze protection. Final system design and installation must follow manufacturer instructions.
Technical Documents
SunEarth THERMORAY Blue TRB-20
